BG790 Industrial-Duty Wishbone Arm Barrier Gate Operator
The LiftMaster BG790 is a heavy-duty wishbone barrier gate operator designed for industrial applications requiring extended reach and robust performance. Purpose-built with a 24-foot wishbone arm and counterweight system, this powerful operator provides reliable access control for wide entrances and specialized industrial applications where traditional barrier arms aren't suitable.
Industrial Construction
- 11-gauge steel cabinet construction
- Weather-resistant powder coat finish
- 60:1 worm gear reducer in oil bath
- Robust 350-pound operator weight
- Durable mechanical limit system
Performance Features
- 1/2 HP AC motor
- 25 cycles per hour duty rating
- 11-second opening time
- 24-foot wishbone arm capacity
- Dual counterweight system included
Control Features
- Security+ 2.0® encrypted technology
- 90 remote control capacity (expandable)
- Multiple power input options
- Mechanical limit settings
- UL325 compliant operation
Specifications
Operational Capacity
- Maximum Arm Length: 24 feet
- Operating Speed: 11 seconds
- Hourly Duty Rating: 25 cycles
- Included: Wishbone arm with counterweights
Power Options
- Single Phase: 120/208/230VAC
- Three Phase: 208/230/460VAC
- Three Phase High Voltage: 575VAC
- Accessory Power: 24VAC
Environmental
- Standard Temperature Range: -4°F to 140°F
- Optional Heater Range: -40°F to 140°F
- Weather-resistant cabinet design
- Industrial-grade components
Construction
- Cabinet: 11-gauge steel construction
- Finish: Powder-coated weather resistance
- Weight: 350 pounds
- UL Usage Classification: I, II, III, and IV
Warranty
- 2-year warranty coverage
Resources
Customer Reviews
Thank you for submitting your review
Is there a timer option i.e. to keep the gate open between certain hours and closed others?
Hello there, and thank you for reaching out to us. Yes there is. It is the Seco-Larm Enforcer SA-027HQ. I will email you the link for that.
What activates the gate?
Gate operators can be activated by a remotes, keypads, card readers, push buttons, underground sensors and above ground sensors to name a few. If we misunderstood your question, feel free to call or contact us via email. We're open M-F 8am-4pm Pacific standard time.
